Keithley 2636B Dual Channel System Sourcemeter
No stress rentals! We help you to choose the equipment that you need, we expedite shipment, and follow up.
Application
- The Keithley 2636B is a dual-channel instrument that combines the capabilities of a precision power supply, true current source, 6½ digit DMM, arbitrary waveform generator, pulse generator, and electronic load.
Key features
- Dynamnic range: 10 A pulse to 0.1 fA and 200 V to 100 nV
- Remote control via built-in web browser based software
- Mobile app enables plug & play with any Android device
- USB 2.0, LXI-C, GPIB, RS-232, and digital I/O interfaces
| Required testing scenario | Suggested Options/Applications |
|---|---|
| Internet of Things (IoT) - EMC | n/a |
| Internet of Things (IoT) - Wireless Standards Compliance | n/a |
| Internet of Things (IoT) - Power Management | The Keithley 2636B is well suited for power management testing situations. No additional options or applications are required. |
| Internet of Things (IoT) - Signal & Power Integrity | n/a |
| Range | Default Display Resolution Single-channel display mode |
Input resistance | Accuracy: ± (% rdg. + volts) |
|---|---|---|---|
| 200 mV | 100 nV | > 1014 Ω | ± (0.015% + 225 μV) |
| 2 V | 1 μV | > 1014 Ω | ± (0.02% + 350 μV) |
| 20 V | 10 μV | > 1014 Ω | ± (0.015% + 5 mV) |
| 200 V | 100 μV | > 1014 Ω | ± (0.015% + 50 mV) |
| Range | Resolution | Voltage burden | Accuracy: ± (% rdg. + amps) |
|---|---|---|---|
| 100 pA | 0.1 fA | <1 mV | ± (0.15% + 120 fA) |
| 1 nA | 1 fA | <1 mV | ± (0.15% + 240 fA) |
| 10 nA | 10 fA | <1 mV | ± (0.15% + 3 pA) |
| 100 nA | 100 fA | <1 mV | ± (0.06% + 40 pA) |
| 1 μA | 1 pA | <1 mV | ± (0.025% + 400 pA) |
| 10 μA | 10 pA | <1 mV | ± (0.025% + 1.5 nA) |
| 100 μA | 100 pA | <1 mV | ± (0.02% + 25 nA) |
| 1 mA | 1 nA | <1 mV | ± (0.02% + 200 nA) |
| 10 mA | 10 nA | <1 mV | ± (0.02% + 2.5 μA) |
| 100 mA | 100 nA | <1 mV | ± (0.02% + 20 μA) |
| 1 A | 1 μA | <1 mV | ± (0.03% + 1.5 mA) |
| 1.5 A | 1 μA | <1 mV | ± (0.05% + 3.5 mA) |
| 10 A | 10 μA | <1 mV | ± (0.4% + 25 mA) |
| IEEE-488 | IEEE-488.1 compliant. Supports IEEE-488.2 common commands and status model topology |
|---|---|
| USB Control (rear) | USB 2.0 device, TMC488 protocol |
| RS-232 | Baud rates from 300 bps to 115200 bps. Programmable number of data bits, parity type, and flow control (RTS/CTS hardware or none) |
| Ethernet | RJ-45 connector, LXI Class C, 10/100BT, no auto MDIX |
| Expansion interface | The TSP-Link expansion interface allows TSP enabled instruments to trigger and communicate with each other |
| Cable type | Category 5e or higher LAN crossover cable |
| Cable length | 3 meters maximum between each TSP enabled instrument |
| USB File System (Front) | USB 2.0 Host: Mass storage class device |
| Power supply | 100 V to 250 VAC, 50-60 Hz (auto sensing), 240 VA max |
| Cooling | Forced air. Side intake and rear exhaust. One side must be unobstructed when rack mounted |
| Dimensions | Without handle & feet: (89 H x 213 W x 460 D)mm (3½ x 8⅜ x 17½)in. With handle & feet: (104 H x 238 W x 460 D)mm (4⅛ x 9⅜ x 17½)in. |
| Weight | 5.50 kg (12.0 lbs) |
| Environment | Maximum 2000 m above sae level. (For indoor use only) Operating: 0°-50°C, 70% R.H. up to 35°C. Derate 3% R.H./°C, 35°-50°C Storage: -25°C to 65°C. |
